Body Composition Analyzer 270

Designed with traveling professionals in mind, the InBody 270 body composition analyzer is portable yet features the accuracy and precision customers expect from InBody.

Bio electrical Impedance Analysis (BIA)

Measurement Items Bio electrical Impedance (Z)

10 Impedance Measurements by Using 2 Different Frequencies

(20kHz, 100kHz) at Each of 5 Segments (Right Arm, Left Arm,

Trunk, Right Leg, and Left Leg)

Electrode Method Tetra polar 8-Point Tactile Electrodes

Measurement Method Direct Segment Multi-frequency Bio electrical Impedance Analysis Method (DSM-BIA )

Simultaneous Multi-frequency Impedance Measurement (SMF-BIA)

Body Composition

Calculation Method No Empirical Estimation

Applied Rating Current 200μA (±40μA)

Adapter Manufacture Bridge Power Corp.

Model BPM040S12F07

Power Input AC 100 - 240V, 50 - 60Hz, 1.2A

Power Output DC 12V, 3.4A

Display Type 480 × 800 7inch Color TFT LCD

Internal Interface Touchscreen, Keypad

External Interface RS-232C 1EA, USB HOST 2EA, USB SLAVE 1EA, LAN (10T) 1EA,

Bluetooth 1EA, Wi-Fi 1EA

Compatible Printer Laser/Inkjet Printers (Printers recommended by InBody)

* A list of printers compatible with the InBody can be found at http://www.inbodyservice.com

Dimension 356 (W) × 796 (L) × 995 (H): mm

14.0 (W) × 31.3 (L) × 39.2 (H) : inch

Equipment Weight 14kg (30.9lbs)

Testing Time About 15 seconds

Operation Environment 10 ~ 40°C, 30 ~ 75% RH, 70 ~ 106kPa

Storage Environment -10 ~ 70°C, 10 ~ 80% RH, 50 ~ 106kPa (No Condensation)

Testing Weight Range 10 ~ 250kg (22.0 ~ 551.2lbs)

Testing Age Range 3 ~ 99 years

Height Range 95 ~ 220cm (3ft. 1.4in. ~ 7ft. 2.61in.)
