The InBody S10 body water analyzer is specifically designed for immobile or amputee patients and uses attachable electrodes to identify excess fluid and assess cellular health.

BODY COMPOSITION ANALYZER of Direct Segment Multi-frequency Bio electrical Impedance Method Bio electrical Impedance(BIA)

Measurement Items Bio electrical Impedance(Z) 30 Impedance Measurements by Using 6 Different Frequencies (1㎑, 5㎑, 50㎑, 250㎑, 500㎑, 1000㎑) at Each of 5 Segments (Right Arm, Left Arm, Trunk, Right Leg and Left Leg) Reactant(Xc) 15 reactant(Xc), phase angle(θ) measurements by using 3 different frequencies (5㎑, 50㎑, 250㎑) at each Phase angle(θ) 5 segments (right arm, left arm, trunk, right leg, left leg)

Electrode Method Tetra polar 8point tactile/adhesive electrode system

Measurement Method Direct Segmental Multi-frequency Bio electrical Impedance Analysis Method; DSM-BIA Method Body Composition Calculation Method No use of Empirical Estimation.

Applied Rating Current Under100uA(1kHz), 500uA(over 5kHz)

Adapter Manufacturer Bridge Power Corp. Model BPM040S12F07

Power Input AC100-240V, 50/60Hz, 1.2A(12A-0.6A)

Power Output DC 12V, 3.4A

Display Type 800 X 480 Touch Color LCD

External Interface RS-232C 1EA, USB Slave 1EA, USB Host 1EA

Compatible Printer Laser/inkjet PCL 3 or above and SPL(Printer recommended by InBody) Thermal Printer (Optional)

Dimensions 202(W) X 322(L) X 53(H): mm / 7.9(W) X 16.6(L) X 2(H): inch

Machine Weight 2kg (4.4lbs) Operation Condition 10 ~ 40℃(50 ~ 104℉ ), 30 ~ 75% RH, 70 ~ 106kPa

Transport and Storage Condition -10~ 70℃(14 ~ 158℉), 10 ~ 85%RH, 50 ~ 106kPa Weight Range(Input) 10 ~ 250kg (22 ~ 551lb.)

Age Range 3 ~ 99years Height Range 95 ~ 220cm (2ft. 9.5in. ~ 7ft. 2.6in.)

Printer
The InBody 270 Thermal Printer is a portable printer that connects to your InBody 270 device. It prints out the body composition analysis results on receipt paper (2 1/4" x 80', 2 1/4" x 85', 2 1/4" x 165) and is convenient to carry with you if you do not have ready access to a full-sized printer.

The BPBIO 320S is a fully automated, non-invasive, and easy-to-use blood pressure monitor. The device features voice-guidance, a single-step measurement process, and an elbow sensor for accurate results and high reproducibility.
DIMENSIONS :-16 (L) x 19.3 (W) x 11 (H) inches
Display Unit :-1mmHg
